Barracuda™ Dual Wet Vacuum by Ramvac
Our dual dental vacuum system incorporates two water-injected pumps in one easily installed cabinet. The system offers full single-pump operation with the second pump providing backup protection or extra power for occasional heavy demand. Quiet and compact, the system features a chemical resistant brass impeller and housing for lasting performance.
Check out our current promotions!
- Dual pump for optimum performance and reliability with powerful vacuum levels during peak operating hours and 100% back up should one motor fail
- Sealed bearings in motor
- Frame provides easier access to motors for maintenance and transport
- 5-year limited warranty from date of installation
- Optional top shelf with a 300-pound capacity for stacking compressor
- Optional air/water and nitrous oxide separator
- Optional water recirculator reduces water consumption by approximately 80% without sacrificing high vacuum power
- Easy 4-step installation with no mounting hardware required
Literature
Ramvac Wet Vacuum Sell Sheet
Quickly access key important benefits and information about our Ramvac wet vacuums.
Utility Catalog
See what the products the Ramvac utility line has to offer. Marvel at our compressors, vacuums, tanks, and more!
Manuals
Barracuda Dual Wet Vacuum System user manual
Barracuda Dual Wet Vacuum site information
Wet Vacuum Pump technical manual
Barracuda Dual Wet Vacuum pre-installation guide
Specifications
Model: Barracuda MC-201FS
Part Number: 64586110D
Recirculator: N/A
Horsepower: 2 x 1 HP
Volts: 208-230
Amps (each motor): 7.5 each motor
Phase: Single
RPM: 3450
Ambient Temperature: 32°C / 104°F
Cycle: 60 Hz
Width: 24"
Depth: 17"
Height: 24"
Shipping Weight: 175 lbs.
Typical Application: 4 Users
Breaker Size: 15 amp
Model: Barracuda MC-201FSW
Part Number: 6458611DW
Recirculator: Included
Horsepower: 2 x 1 HP
Volts: 208-230
Amps (each motor): 7.5 each motor
Phase: Single
RPM: 3450
Ambient Temperature: 32°C / 104°F
Cycle: 60 Hz
Width: 26"
Depth: 20"
Height: 24"
Shipping Weight: 175 lbs.
Typical Application: 4 Users
Breaker Size: 15 amp
Model: Barracuda MC-202FS
Part Number: 64586211D
Recirculator: N/A
Horsepower: 2 x 2 HP
Volts: 208-230
Amps (each motor): 15 each motor
Phase: Single
RPM: 3450
Ambient Temperature: 32°C / 104°F
Cycle: 60 Hz
Width: 24"
Depth: 17"
Height: 24"
Shipping Weight: 215 lbs.
Typical Application: 6 Users
Breaker Size: 20 amp
Model: Barracuda MC-202FSW
Part Number: 6458621DW
Recirculator: Included
Horsepower: 2 x 2 HP
Volts: 208-230
Amps (each motor): 15 each motor
Phase: Single
RPM: 3450
Ambient Temperature: 32°C / 104°F
Cycle: 60 Hz
Width: 26"
Depth: 20"
Height: 24"
Shipping Weight: 215 lbs.
Typical Application: 6 Users
Breaker Size: 20 amp
